Hikvision DS-K2708X 8-Door Ultra Series Access Controller

Hikvision DS-K2708X Ultra-Series 8-Door Network Access Controller

Product Code: DS-K2708X

Access Controller

Supports 8-door control. It is formed by 2 DS-K2M002X access modules, and one 4-doors access controller
Access controller: downstream RS-485 redundancy wiring design to ensure communication stability. 5-ch downlink RS-485 interface supports two applications: 1. When 4-ch RS-485 communication, the 5th RS-485 can be used as a redundant application; 2. 4-ch RS-485 forms 2 groups of dual-bus loops with physical isolation. It is recommended that you do not have more than 16 access modules attached to each loop bus. Access Module: supports 8-ch RS-485 interface for card reader connecting
Web configuration management. All configurations can be realized via web without software application
Supports professional access control applications such as multi-door interlocking and anti-passback
Supports backup battery access. Charging and discharging are available
It has status indicators such as power supply, communication and operation, which is convenient for equipment health detection

Product Code: DS-K2708X

Access Controller

Supports 8-door control. It is formed by 2 DS-K2M002X access modules, and one 4-doors access controller
Access controller: downstream RS-485 redundancy wiring design to ensure communication stability. 5-ch downlink RS-485 interface supports two applications: 1. When 4-ch RS-485 communication, the 5th RS-485 can be used as a redundant application; 2. 4-ch RS-485 forms 2 groups of dual-bus loops with physical isolation. It is recommended that you do not have more than 16 access modules attached to each loop bus. Access Module: supports 8-ch RS-485 interface for card reader connecting
Web configuration management. All configurations can be realized via web without software application
Supports professional access control applications such as multi-door interlocking and anti-passback
Supports backup battery access. Charging and discharging are available
It has status indicators such as power supply, communication and operation, which is convenient for equipment health detection

Description

The Hikvision DS-K2708X is an Ultra-Series 8-door network access controller designed for enterprise-grade access control systems. It supports up to 8 doors and 16 card readers, with high-capacity storage for 100,000 users, 200,000 cards, 10,000 fingerprints and 600,000 event logs. The controller uses Gigabit Ethernet and web-based configuration, and includes advanced access functions such as anti-passback, multi-door interlock, multi-factor authentication and fire interface support. It also offers backup battery charging/discharging capability, RS-485 redundant wiring design and comprehensive I/O interfaces for locks, alarms and door contacts

Reviews

Customer reviews

No reviews left yet

Write a review

No reviews have been left for this product, be the first to leave a review

Attributes

Brand:

Hikvision

Product Code:

DS-K2708X
